What is an aerodrome reference code?

An aerodrome reference code is a design classification, usually written as a number and a letter. It isn’t the passenger airport identifier on a baggage label, and it isn’t a universal permission for an aircraft to use a runway.

Illustration of a passenger aircraft’s wingspan beside a runway.

Aerodrome reference code: the number and the letter

CAA CAP168, Table 3.1 and paragraphs 3.15–3.17, describes the number using aeroplane reference field length and the letter using wingspan. The code helps relate aerodrome design to the aircraft for which facilities are intended.

ElementWhat it describesWhat it does not identify
NumberReference field-length categoryThe airport’s passenger code
LetterWingspan categoryA unique airport or airline

The full aerodrome reference code table

The thirteenth edition of CAP168, dated July 2025, sets out the whole scale in Table 3.1. The number is chosen from the highest aeroplane reference field length among the aeroplanes the runway is intended for. The letter is chosen from the greatest wingspan among the aeroplanes the facility is intended for.

Aerodrome reference code, from CAA CAP168 Table 3.1
CodeMeasured byRange
1Reference field lengthLess than 800 m
2Reference field length800 m up to but not including 1,200 m
3Reference field length1,200 m up to but not including 1,800 m
4Reference field length1,800 m and over
AWingspanUp to but not including 15 m
BWingspan15 m up to but not including 24 m
CWingspan24 m up to but not including 36 m
DWingspan36 m up to but not including 52 m
EWingspan52 m up to but not including 65 m
FWingspan65 m up to but not including 80 m

For wingspans greater than 80 metres, a note to the table points to ICAO’s Aerodrome Design Manual (Doc 9157) for planning guidance. The reference field length has a fixed meaning in the CAP168 glossary: the minimum field length required for take-off at maximum take-off weight, calculated at mean sea level, in standard atmosphere conditions and still air, with zero runway slope. The precise distance, the glossary adds, is given in the flight manual or the manufacturer’s equivalent datasheets.

Five plain white airliners parked nose to tail on a concrete apron, green fields and hedges behind.
The letter in the code follows the widest wingspan a facility is meant to take.

A worked example: 4C

ElementCAP168 category
4Aeroplane reference field length of 1,800 metres or more
CWingspan of at least 24 metres but less than 36 metres

Read 4C as those two categories together. It doesn’t say the physical runway is exactly 1,800 metres long, identify an airport, or provide the approved performance calculation for a particular flight.

Why a reference length is not the runway length

CAP168 explicitly separates selection of the code number from the actual runway length provided. It also says the reference code does not determine pavement strength. So a number-and-letter classification cannot, on its own, answer whether a particular aircraft operation is permitted or what take-off distance it needs.

That’s why this explanation stops short of an operational calculator. Reading a design label is useful; treating it as aircraft-performance approval would answer a different question without the necessary information.

An aerial view of a runway threshold by the sea, the markings 22 and L painted beyond white stripes.
Paint on the runway gives its direction; the reference code sits in the design documents. Photo: Olivier Cleynen, Wikimedia Commons, CC BY-SA 4.0, cropped.

Reference codes vs IATA and ICAO airport codes

STN and EGSS identify London Stansted in IATA and ICAO systems. An aerodrome reference code describes a design category instead. The words “airport code” can refer to different things in search results, so establish which system the document is discussing before comparing its labels.

For identifiers, use what an airport code is and the airport lookup. For the physical area the aircraft uses, read what a runway is. For technical requirements, consult the current applicable aerodrome standard. This short explanation is not design advice.
